ARW-255E MULTIFUNCTION EM-LOCK
ARW-255E Multifunction em-lock. This magnetic lock, the overall design is simple, easy to install, the body installation position is adjustable.
Specifications
- Transmitting and receiving code type
- Microwave self-learning
- Lock body
- 71(L) x 65(W) x 45(D) mm
- Suction
- 60(L) x 32(W) x 10(D) mm
- Lock body bracket
- 147(L) x 65(W) x 3(D) mm (Large)
- Suction bracket
- 116(L) x 68(W) x 38(D) mm (Large)
- Action current
- 130mA
- Static current
- 18mA
- Frequency
- 315MHz
- Power input
- AC/DC 24V (Built-in 12V regulated power output)
- Remote control distance
- bout 20 meters
Multifunction Em-Lock
MULTIFUNCTION EM-LOC ARW-255E This magnetic lock, the overall design is simple, easy to install, the body installation position is adjustable, can be flexible assembled on the automatic door.
Adopt the unique demagnetization circuit design, to ensure eliminate residual magnetism.
With new function of remote control 4 key switch (Lock,unidirectional, full open, induction) Power input with AC/DC 24V, built-in 12V regulator circuit, can output DC12V and power on access control machine.
Built-in unlocking status indicator light, easy to maintain the automatic door.
Adsorption plate fixing parts can be adjusted in any direction, easy to install.
The maximum tension is 80KG (176LBS).
Low power consumption, stable and reliable.
